Yaskawa
ACP01-E
No reviews
SKU: 2100000019762
$2,136.00
Contact us for pricing
2-Year Warranty
Free Diagnostics
5–30 Day Turnaround
Nationwide Service
Repair option: send in your faulty unit for component-level repair — $2,136.00 with free diagnostics, a 2-year warranty, and a 5–30 business day turnaround. Repair typically costs 40–70% of a new unit, saving you 30–60%.
Yaskawa ACP01-E repair service is available for facilities running Motoman YRC1000 robot controllers that have experienced CPU board failures, communication faults, or complete controller shutdowns — and Yaskawa ACP01-E refurbished units offer a cost-effective alternative when lead times on new boards stretch into weeks. The ACP01-E is the main CPU PC board housed inside the YRC1000 robot controller cabinet, operating at 24 VDC and serving as the central processing hub that coordinates all motion planning, I/O communication, safety interlocks, and teach pendant interfacing for Motoman industrial robots. When this board fails, the entire robot cell goes down, making fast turnaround on ACP01-E repair a production-critical priority for automotive, metal fabrication, and material handling operations. Technicians performing ACP01-E troubleshooting often report symptoms including blank pendant screens, persistent alarm codes that cannot be cleared, loss of encoder feedback, or the controller failing to complete its boot sequence. If your facility is searching for ACP01-E repair near me, it is worth knowing that a qualified industrial VFD repair and robotics electronics specialist can often restore the original board rather than sourcing an expensive OEM replacement. The board manages real-time trajectory calculations and axis interpolation at the millisecond level, so even subtle firmware corruption or capacitor degradation can manifest as erratic motion or mid-cycle faults. Flexa Systems provides ACP01-E repair with free diagnostics, a 2-year warranty, and nationwide shipping from our facility in Lewisville, TX.
Technical Specifications
Part Number
ACP01-E
Manufacturer
Yaskawa
Voltage
24 VDC
Package / Type
CPU / Control Board
Compatibility
The ACP01-E is compatible with the Yaskawa Motoman YRC1000 controller platform, which supports a broad family of Motoman robots including the GP-series (GP7, GP12, GP25, GP50) and the HC-series collaborative arms. Yaskawa ACP01-E integration with the YRC1000 architecture relies on the board communicating with subordinate motion control boards such as the SRDA-MXP01A and JANCD-MCP01-E over the controller's internal MECHATROLINK-III backplane bus. The ACP01-E replacement for a failed CPU board must match the specific firmware revision and board variant designated for the connected robot model, as mismatched firmware can cause axis configuration errors or safety circuit faults. For facilities integrating the YRC1000 into broader automation networks, the controller supports EtherNet/IP, DeviceNet, PROFIBUS-DP, and OPC-UA communication standards, all of which are initialized and managed through the ACP01-E main CPU board.
Service Options
Repair Service
Ship your faulty ACP01-E to our facility. Our certified technicians perform IGBT testing, capacitor inspection, gate driver diagnostics, and full load testing. Typical turnaround: 5–7 business days. 2-year warranty included.
Refurbished
In-stock Yaskawa ACP01-E variable frequency drive, reconditioned to OEM specifications and verified under load. Ships immediately. 2-year warranty included.
Brand New
New ACP01-E in original Yaskawa packaging. Full manufacturer warranty applies. Contact us to confirm availability and lead time.
Common Failure Modes
Persistent ALM-4310 (CPU communication error) fault on power-up, traced to failed oscillator circuitry on the ACP01-E board preventing the processor from synchronizing with the MECHATROLINK-III internal bus.
ACP01-E fault code ALM-8500 (safety circuit open) appearing without any physical E-stop activation, caused by degraded logic-level MOSFETs on the board misreading the dual-channel safety input voltage at the 24 VDC threshold.
Complete loss of teach pendant communication (blank DX200/YRC1000 pendant screen) due to failed USB host controller IC on the ACP01-E, a known wear failure in high-cycle welding cell environments with elevated ambient temperatures above 45°C.
ACP01-E troubleshooting for ALM-4101 (encoder data receive error) frequently points to corrupted FPGA configuration memory on the main CPU board rather than the encoder or wiring, particularly in units with more than 40,000 power-cycle hours.
Frequently Asked Questions
Is the ACP01-E compatible with older Yaskawa Motoman controller platforms, or is it a direct replacement for any DX200 CPU boards?
The ACP01-E is not directly interchangeable with DX200-era CPU boards such as the JANCD-YCP21-E, as the YRC1000 and DX200 use different backplane architectures and firmware ecosystems. However, ACP01-E replacement for a defective board within the YRC1000 family is straightforward provided the board revision and robot model designation match — Yaskawa catalogs the GP7, GP12, and GP25 variants separately. Facilities migrating from DX200 controllers should treat the ACP01-E as a platform-specific component rather than a cross-generation swap, and should consult Yaskawa part documentation to confirm the correct JANCD or SRDA pairing for their specific cell configuration.
How do I know whether my ACP01-E is worth repairing or if I should replace it outright?
Most ACP01-E repair cases are economically viable unless the board has sustained physical damage such as burnt PCB traces, cracked BGA solder joints from a drop or crush event, or corrosion from coolant contamination that has reached the processor package. Common repairable conditions include failed capacitors causing boot instability, damaged communication ICs producing ALM-4310 faults, or corrupted flash memory causing the Yaskawa ACP01-E to cycle through alarms without completing initialization. A board that shows no visible burn damage and still powers to a partial boot state has a high recovery rate in the hands of a qualified repair technician. ACP01-E repair is typically 40–60% of the cost of a new OEM board, making diagnostics the logical first step before committing to full replacement.
Where can I get ACP01-E repair service with a warranty?
Flexa Systems, based in Lewisville, TX, provides ACP01-E repair service with a 2-year warranty and an average turnaround of 5–7 business days, with rush options available for facilities facing critical downtime. Every board goes through free diagnostics before a repair quote is issued, so there is no cost to find out whether your unit is recoverable. Flexa ships nationwide, making it a practical option whether you are looking for ACP01-E repair near me in the Dallas area or sending a board in from a facility across the country. For facilities that need a unit immediately, Flexa also carries ACP01-E refurbished stock, so you can buy ACP01-E USA with same-week availability while your original board undergoes repair.
Where can I get ACP01-E repair service with a warranty?
Flexa Systems provides professional ACP01-E repair service from our facility in Lewisville, TX, serving customers nationwide. Standard turnaround is 5–7 business days from receipt and all repaired units ship with a 2-year warranty. Rush service (2–3 business days) is also available.
Flexa Systems specializes in Yaskawa ACP01-E variable frequency drive repair, supplying refurbished and new units backed by a 2-year warranty. All drives are load-tested before shipping. Serving industrial facilities nationwide from Lewisville, TX.
