Allen-Bradley

Allen-Bradley 22A-B1P5N104

SKU: 2100000017607

$373.00

2-Year Warranty

Free Diagnostics

5–30 Day Turnaround

Nationwide Service

Repair option: send in your faulty unit for component-level repair — $335.00 with free diagnostics, a 2-year warranty, and a 5–30 business day turnaround. Repair typically costs 40–70% of a new unit, saving you 30–60%.

22A-B1P5N104 repair service is a core offering at Flexa Systems, where our technicians specialize in restoring the ALLEN BRADLEY 22A-B1P5N104 repair to full factory specification — and we also carry 22A-B1P5N104 refurbished stock for facilities that need a faster swap-out solution. This unit is a compact PowerFlex 4 series AC variable frequency drive rated at 240 VAC three-phase input, delivering 1.5 amps of output current to control a 0.2 kW (0.35 HP) motor with precision speed regulation. It is widely deployed in light conveyor systems, small pump stations, packaging equipment, and HVAC auxiliary fan motors where compact footprint and reliable speed control are critical. Customers frequently search for 22A-B1P5N104 troubleshooting support after encountering nuisance trips caused by environmental contaminants or capacitor degradation common in units with several years of service. The drive supports sensorless vector and V/Hz control modes, making it appropriate for constant-torque and variable-torque loads in food processing, material handling, and water treatment facilities. If you need industrial VFD repair handled quickly without scrapping a functioning control panel, our bench diagnostics process can identify IGBT failures, gate driver faults, and control board corruption within 24 hours of receipt. For those asking about 22A-B1P5N104 repair near me, Flexa Systems ships repaired units nationwide from our facility in Lewisville TX, with a fast turnaround that minimizes production downtime. Free diagnostics are included with every repair submission, so you know exactly what failed before committing to a service quote.

Technical Specifications

Part Number	22A-B1P5N104
Manufacturer	ALLEN BRADLEY
Voltage	240 VAC 3 PHASE
Current Rating	1.5 AMP
Power Rating	0.2 KW / 0.35 HP
Package / Type	POWERFLEX 4

Compatibility

The 22A-B1P5N104 is compatible with Allen-Bradley's broader PowerFlex 4 and PowerFlex 40 control ecosystem, and ALLEN BRADLEY 22A-B1P5N104 integration into existing MicroLogix 1100, MicroLogix 1400, and CompactLogix L-series PLC architectures is straightforward using the drive's built-in RS-485 DSI communication port with an optional 22-SCM-232 or 22-HIM-A3 interface module. The 22A-B1P5N104 compatible with DeviceNet networks can be achieved by adding the 22-COMM-D communication adapter, while EtherNet/IP connectivity is available via the 22-COMM-E module for facilities running Studio 5000 Logix Designer with connected components workbench. A 22A-B1P5N104 replacement for the earlier 22A-B1P5H304 or the legacy 1305 Series drives is feasible in most panel configurations, provided input line reactors (such as the 1321-3R series) and output filters are retained for EMI compliance. The drive accepts standard NEMA frame T-frame motors with 230V three-phase windings, and its I/O terminal block supports 0–10V analog speed reference and dry-contact digital inputs compatible with most PLC sourcing or sinking output cards.

Service Options

Repair Service

Ship your faulty 22A-B1P5N104 to our facility. Our certified technicians perform IGBT testing, capacitor inspection, gate driver diagnostics, and full load testing. Typical turnaround: 5–7 business days. 2-year warranty included.

Refurbished

In-stock ALLEN BRADLEY 22A-B1P5N104 variable frequency drive, reconditioned to OEM specifications and verified under load. Ships immediately. 2-year warranty included.

Brand New

New 22A-B1P5N104 in original ALLEN BRADLEY packaging. Full manufacturer warranty applies. Contact us to confirm availability and lead time.

Common Failure Modes

DC bus overvoltage fault (F005) triggered on deceleration when default decel ramp time is too short for the connected load inertia — particularly common in 22A-B1P5N104 troubleshooting cases where no dynamic braking resistor is installed.
Output IGBT short-circuit fault (F012) resulting from moisture ingress into the drive enclosure, which causes carbonized tracking across the gate driver PCB and destroys one or more of the three-phase output transistors — a frequent finding in 22A-B1P5N104 fault investigations from wash-down or high-humidity environments.
Input rectifier diode failure presenting as an unbalanced DC bus voltage reading below 280 VDC under no-load conditions, often preceded by repeated undervoltage faults (F004) due to single-phasing caused by a cracked solder joint on the rectifier bridge — common in units exceeding 7 years of continuous cyclic service.
Control board EEPROM corruption causing the drive to revert to factory defaults on every power cycle, losing all programmed parameters including accel/decel times, motor nameplate data, and analog input scaling — typically triggered by a momentary power interruption during an active parameter write operation or by electrostatic discharge during field servicing.

Frequently Asked Questions

Is the 22A-B1P5N104 compatible with or interchangeable with other PowerFlex drive models?

The 22A-B1P5N104 compatible with the PowerFlex 4M series shares the same DSI communication architecture and similar terminal layout, making cross-substitution practical in many panel builds when firmware and parameter configurations are re-entered. The PowerFlex 40 (22B series) is a functional step-up replacement that adds full V/Hz and sensorless vector tuning capability, and many engineers treat it as the preferred 22A-B1P5N104 replacement for applications where expanded PID or network features are needed. In competitive replacement scenarios, the ABB ACS150 and Siemens SINAMICS V20 in equivalent 0.37 kW 240V ratings have been used as substitutes, but Allen-Bradley panel wiring conventions and PLC messaging configurations typically require modification. Always verify the replacement drive's output current rating meets or exceeds 1.5 amps continuous to avoid thermal derating on the target motor.

How do I know if my 22A-B1P5N104 is worth repairing or if I should replace it outright?

A 22A-B1P5N104 repair is generally cost-effective when the failure is isolated to the control board, gate driver section, or DC bus capacitors, as these components are serviceable and the ALLEN BRADLEY 22A-B1P5N104 power structure is well-documented. Units showing physical damage such as burned or cracked power modules, severely corroded bus bars, or catastrophic IGBT failure across all three phases may cross the economic threshold where a refurbished or new replacement makes more sense depending on production criticality. Fault codes F002 (accelerating), F007 (motor overload), or F012 (output phase) that return immediately after a reset are strong indicators of a hardware fault rather than a parameter issue and warrant bench-level diagnosis. If the drive is powering up but displaying persistent F008 or F004 faults with confirmed clean input power, capacitor degradation is the most likely cause and is a straightforward repair at a fraction of replacement cost.

Where can I get 22A-B1P5N104 repair service with a warranty?

Flexa Systems, based in Lewisville TX, provides depot-level 22A-B1P5N104 repair service backed by a 2-year warranty on all completed repairs, covering both parts and labor for the repaired fault condition. Every unit received undergoes free diagnostics before a repair quote is issued, so customers have full visibility into the failure before authorizing work — typical bench-to-ship turnaround runs 5 to 7 business days. Flexa Systems serves customers nationwide with prepaid inbound shipping options and same-day outbound shipping on completed units, making it a practical solution whether you are searching for 22A-B1P5N104 repair near me or coordinating from across the country. For facilities that need an immediate swap, Flexa also maintains refurbished exchange inventory, so you can buy 22A-B1P5N104 USA stock off the shelf and ship your core back for credit.

Where can I get 22A-B1P5N104 repair service with a warranty?

Flexa Systems provides professional 22A-B1P5N104 repair service from our facility in Lewisville, TX, serving customers nationwide. Standard turnaround is 5–7 business days from receipt and all repaired units ship with a 2-year warranty. Rush service (2–3 business days) is also available.

Flexa Systems specializes in ALLEN BRADLEY 22A-B1P5N104 variable frequency drive repair, supplying refurbished and new units backed by a 2-year warranty. All drives are load-tested before shipping. Serving industrial facilities nationwide from Lewisville, TX.
