Allen-Bradley 2094-AM01
Repair option: send in your faulty unit for component-level repair — $710.00 with free diagnostics, a 2-year warranty, and a 5–30 business day turnaround. Repair typically costs 40–70% of a new unit, saving you 30–60%.
2094-AM01 repair service is a core specialty at Flexa Systems, where our technicians regularly restore these Allen Bradley axis modules to full factory specification — and if your timeline is tight, a 2094-AM01 refurbished exchange unit can ship same-day while your original is being evaluated for ALLEN BRADLEY 2094-AM01 repair. The 2094-AM01 is a single-axis power module belonging to the Kinetix 6000 multi-axis servo drive family, rated at 200/230V AC nominal input with a 9-amp continuous output current and 1.9 kW power rating, making it suited for compact servo motion applications where panel space and power density both matter. If you've been searching for 2094-AM01 repair near me, Flexa Systems ships nationwide from our Lewisville TX facility, so geography is never a barrier to getting your line back up. This module is commonly deployed in precision assembly, packaging machinery, labeling systems, and light CNC applications where tight velocity and torque loop control are required. Industrial VFD repair at this power class demands component-level expertise — particularly around the IGBT switching stage and gate driver circuitry that are stress points on these units. For teams working through 2094-AM01 troubleshooting, Flexa provides free diagnostics with every unit received, so you'll have a clear repair assessment before any commitment is made. All repaired units leave our facility load-tested under actual motor conditions to validate current loop stability and encoder feedback integrity before shipment.
The 2094-AM01 is compatible with the Allen Bradley Kinetix 6000 multi-axis servo drive system and is designed to mount alongside the 2094-AC09-M01-S IAM (Integrated Axis Module), sharing a common DC bus architecture that eliminates redundant rectifier stages across axes. ALLEN BRADLEY 2094-AM01 integration is supported natively through the SERCOS fiber-optic communication ring used in ControlLogix and CompactLogix platforms, with motion configuration handled via Studio 5000 Logix Designer using the Axis Properties dialog. The 2094-AM01 is a direct 2094-AM01 replacement for other Kinetix 6000 AM modules such as the 2094-AM02 (higher current variant) in applications where the lower power rating is sufficient, and it is also catalog-comparable to the earlier 2093-AM1 Kinetix 2000 axis module for legacy system upgrades. Compatible feedback devices include incremental encoders, 1326 series Allen Bradley servo motors, and MPL-series motors such as the MPL-B310P, with the module supporting up to 200V-class motor frames typically used in the 40–90mm flange range.
- Output IGBT open-circuit fault (Axis Fault — Drive Hardware) on one or more phases, typically caused by thermal cycling fatigue in the IGBT module solder joints — a known stress point in 2094-AM01 units running frequent start/stop duty cycles at high ambient temperatures.
- DC bus undervoltage fault triggered during acceleration ramps, often traced to degraded bulk capacitance in the shared DC bus — 2094-AM01 troubleshooting should include capacitance ESR measurement on the bus filter capacitors as a first diagnostic step.
- Gate driver power supply failure causing a latched inhibit state where the axis will not enable and the drive remains in a fault condition with no motion output, even after fault clear commands from the ControlLogix controller — a recurring 2094-AM01 fault in units with more than 40,000 operating hours.
- Encoder feedback loss fault (Axis Fault Code 13 — Feedback Device Failure) resulting from corrosion or mechanical damage to the D-sub feedback connector pins, commonly seen in 2094-AM01 units installed in washdown-adjacent environments where condensation infiltrates the connector housing over time.
Technical Specifications
| Part Number: | 2094-AM01 |
| Manufacturer: | ALLEN BRADLEY |
| Voltage: | 200/230V AC nominal |
| Current: | 9 Amps |
| Power: | 1.9 kW |
| Type: | KINETIX 6000 |
