Allen-Bradley 2094-AC09-M02
Repair option: send in your faulty unit for component-level repair — $909.00 with free diagnostics, a 2-year warranty, and a 5–30 business day turnaround. Repair typically costs 40–70% of a new unit, saving you 30–60%.
2094-AC09-M02 repair service is a core specialty at Flexa Systems, where our technicians handle ALLEN BRADLEY 2094-AC09-M02 repair daily — and we also carry 2094-AC09-M02 refurbished units for facilities that need an immediate swap-out. The 2094-AC09-M02 is an AC input power module within Allen-Bradley's Kinetix 6000 multi-axis servo drive system, rated for 195–264 V AC input at up to 15 A continuous current and supporting 6–12 kW output power configurations. Engineers searching for 2094-AC09-M02 troubleshooting resources will find this module particularly sensitive to input line transients, since the internal bus capacitor bank and inrush limiting circuitry are common failure points in high-cycle manufacturing environments. The module is widely deployed in packaging machinery, CNC tooling lines, and automated assembly systems where precise multi-axis coordination is required. If you've been hunting for 2094-AC09-M02 repair near me, it's worth knowing that Flexa Systems ships nationwide and offers the same fast turnaround as any local shop — often faster. Our industrial VFD repair process includes full load testing at rated voltage before any unit leaves our facility. Understanding 2094-AC09-M02 fault codes is essential to diagnosing whether the issue originates in the power module itself or in an upstream line conditioner or downstream axis module.
The 2094-AC09-M02 is compatible with the Allen-Bradley Kinetix 6000 multi-axis servo drive family and is designed to pair directly with 2094-series axis modules such as the 2094-AM02, 2094-BM02-S, and 2094-BC02-M02-S on a shared DC bus configuration. ALLEN BRADLEY 2094-AC09-M02 integration is supported through RSLogix 5000 and Studio 5000 Logix Designer software using the SERCOS motion network interface native to Kinetix 6000 axis drives. The 2094-AC09-M02 compatible with ControlLogix and CompactLogix controller platforms, communicating via 1756-series motion modules such as the 1756-M08SE, making it a 2094-AC09-M02 replacement for earlier 2094-AC09-M01 power modules in existing panel configurations where wiring and rail mounting remain unchanged. Input reactor modules in the 2090-series and Allen-Bradley Bulletin 1321 line reactors are supported upstream, and the unit is compatible with NEMA frame B and C servo motors wired through 2090-series feedback and power cables.
- Gate drive power supply failure on the IGBT bridge causing a persistent Motor Stall or Hardware Fault (E-code HW) — a known 2094-AC09-M02 fault pattern in facilities with unstable 208–240 V supply voltage that repeatedly dips below the 195 V AC minimum input threshold.
- DC bus precharge relay weld-failure after repetitive emergency-stop cycling, resulting in an Illegal Hardware Config fault on powerup — technicians performing 2094-AC09-M02 troubleshooting should measure bus voltage bleed-down time, as a welded relay prevents proper capacitor precharge sequencing.
- Shorted or open DC bus capacitors presenting as recurring Bus Overvoltage (BUS-OV) or Bus Undervoltage (BUS-UV) faults during deceleration, typically accelerated by ambient temperatures exceeding 40°C inside enclosures with failed cooling fans.
- Corrupted or failed internal firmware memory in the power module's embedded microcontroller, causing the Kinetix 6000 system to report a Module Not Responding fault on the SERCOS ring — often misdiagnosed as a failed axis module before the shared AC input module is isolated as the root cause.
Technical Specifications
| Part Number: | 2094-AC09-M02 |
| Manufacturer: | ALLEN BRADLEY |
| Voltage: | 195–264 V AC |
| Current: | 15 A |
| Power: | 6-12 Kw |
| Type: | KINETIX 6000 |
