Allen-Bradley 2093-AM02
Repair option: send in your faulty unit for component-level repair — $1,220.00 with free diagnostics, a 2-year warranty, and a 5–30 business day turnaround. Repair typically costs 40–70% of a new unit, saving you 30–60%.
2093-AM02 repair service is in high demand for this Allen Bradley 200V class shared DC bus power inverter, and sourcing a properly reconditioned ALLEN BRADLEY 2093-AM02 repair or 2093-AM02 refurbished unit is often the fastest path back to production. Rated at 9.5A continuous output current and 3.0 kW at 230V AC, this inverter module is engineered to operate within the Kinetix 6000 multi-axis servo drive system, sharing a common DC bus rail across multiple axes to reduce overall cabinet energy consumption and heat dissipation. For maintenance teams researching 2093-AM02 troubleshooting steps, understanding that this unit functions as a power inverter — not a standalone drive — is critical, since its gate drive circuitry, IGBT modules, and DC bus capacitors are all sized specifically for coordinated multi-axis motion control environments such as packaging machinery, CNC retrofit systems, and high-cycle assembly lines. Facilities dealing with recurring faults should evaluate 2093-AM02 fault codes through the Kinetix 6000 IAM or AM module diagnostics in Studio 5000 Logix Designer before condemning the unit outright. Industrial VFD repair specialists can often restore these inverters to factory performance even after IGBT failure or capacitor degradation, which is significantly more cost-effective than purchasing a new replacement. Flexa Systems provides industrial automation repair from our facility in Lewisville TX, serving customers nationwide with fast turnaround on Kinetix series components. Engineers searching for 2093-AM02 repair near me will find that depot-level service with proper dynamometer load testing is the only way to fully validate inverter health before reinstallation.
The 2093-AM02 is compatible with the Allen Bradley Kinetix 6000 multi-axis servo drive system, where it functions as an Additional Axis Module (AM) sharing a common DC bus with an Integrated Axis Module (IAM) such as the 2093-AC05-MP1 or 2093-AC05-MP2. ALLEN BRADLEY 2093-AM02 integration requires connection to the IAM via the shared DC bus connector and the inter-module ribbon cable, and the system communicates with ControlLogix or CompactLogix PLCs over SERCOS fiber-optic network using RSLogix 5000 or Studio 5000 Logix Designer. The 2093-AM02 is a direct 2093-AM02 replacement for other AM modules in the 2093 series such as the 2093-AM01 (lower current rating) when load requirements fall within its 9.5A output specification, and it supports 200V class motors with standard resolver or high-resolution encoder feedback depending on the paired IAM configuration. Compatible motor cables, input reactors, and shielded feedback cables from Allen Bradley's 2090 accessory series are required to maintain CE and UL compliance within the Kinetix 6000 system architecture.
- Gate drive power supply failure causing the Kinetix 6000 system to report an Axis Inhibited or Module Fault status on the 2093-AM02 axis, with no motor current output despite a healthy DC bus voltage present at the shared bus connectors.
- IGBT output bridge failure resulting in asymmetric phase current output — a common finding during 2093-AM02 troubleshooting when the hosting system logs a Motor Stall (E19) or Overcurrent fault and the motor exhibits cogging or excessive heat at low speeds.
- DC bus capacitor ESR degradation causing intermittent bus undervoltage faults (E13) during high-deceleration cycles in multi-axis Kinetix 6000 systems — particularly prevalent in 2093-AM02 units with over 40,000 operating hours in high-ambient-temperature enclosures.
- Inter-module ribbon cable connector corrosion or micro-fracture causing loss of communication between the 2093-AM02 and the IAM, logged as a Module Communication Fault in Studio 5000 and often misdiagnosed as a PLC backplane or network error before the inverter module is inspected.
Technical Specifications
| Part Number: | 2093-AM02 |
| Manufacturer: | ALLEN BRADLEY |
| Voltage: | 230V AC (200V class shared DC bus power inverter) |
| Current: | 9.5 A |
| Power: | 3.0 kW |
| Type: | KINETIX 2000 |
