Parker
HV341-01-10
No reviews
SKU: 2100000019366
$890.00
Contact us for pricing
2-Year Warranty
Free Diagnostics
5–30 Day Turnaround
Nationwide Service
Repair option: send in your faulty unit for component-level repair — $700.00 with free diagnostics, a 2-year warranty, and a 5–30 business day turnaround. Repair typically costs 40–70% of a new unit, saving you 30–60%.
Parker HV341-01-10 repair service is available for this HV Series stepper motor driver, and facilities managing aging Parker motion control equipment will also find HV341-01-10 refurbished units a cost-effective alternative to new procurement. The Parker HV341-01-10 is a Frame Size 34, single-stack stepper motor drive configured with a single output shaft and a 10-foot integrated cable, rated at 2.74 A RMS — a specification that places it squarely in precision positioning applications where consistent torque output at low speeds is critical. Though categorized under Parker's VFD product family in distribution systems, this unit functions as a dedicated stepper motor driver within the HV Series, commonly deployed in medical device automation, laboratory instrumentation, semiconductor handling, and small-axis CNC positioning stages. Technicians performing HV341-01-10 troubleshooting should note that the integrated 10-foot cable assembly is a common failure point, particularly in installations with repetitive flex cycles or high-vibration enclosures. Those searching for HV341-01-10 repair near me will find that specialized industrial VFD repair shops with Parker motion experience can address driver board failures, current regulation faults, and cable connector degradation that generic repair centers typically cannot. The HV Series platform was engineered for compact, single-axis stepper control where open-loop positioning accuracy and thermal efficiency matter in space-constrained panel builds.
Technical Specifications
Part Number
HV341-01-10
Manufacturer
Parker
Current Rating
2.74 A RMS
Package / Type
Compumotor
Compatibility
The HV341-01-10 is compatible with Parker's NEMA Frame 34 stepper motors across the HV Series lineup, and Parker HV341-01-10 integration is straightforward with Parker's Aries and Gemini indexer/drive platforms when used as a coordinated multi-axis system. HV341-01-10 compatible with Parker 6K Series motion controllers (6K4, 6K8) via step/direction interface, as well as standalone indexers like the Parker Compumotor OEM770 and OEM650 when step-and-direction signaling is used. As an HV341-01-10 replacement for legacy Parker Compumotor HV232 or HV233 stepper driver assemblies, the HV341-01-10 maintains the same frame size mechanical footprint, though cable pinout verification against the OEM wiring diagram is required before substitution. The unit accepts standard TTL-level step and direction inputs, making it broadly interoperable with motion controllers from Galil, Pacific Scientific, and Allen-Bradley ControlLogix platforms configured for open-loop stepper axis control.
Service Options
Repair Service
Ship your faulty HV341-01-10 to our facility. Our certified technicians perform IGBT testing, capacitor inspection, gate driver diagnostics, and full load testing. Typical turnaround: 5–7 business days. 2-year warranty included.
Refurbished
In-stock Parker HV341-01-10 variable frequency drive, reconditioned to OEM specifications and verified under load. Ships immediately. 2-year warranty included.
Brand New
New HV341-01-10 in original Parker packaging. Full manufacturer warranty applies. Contact us to confirm availability and lead time.
Common Failure Modes
Phase-to-phase short in the output stage causing immediate overcurrent shutdown on enable signal — a documented HV341-01-10 fault pattern in units exposed to condensation ingress at the motor cable connector over extended service periods.
Current regulation instability resulting in mid-travel motor stall or position loss, typically traced to degraded sense resistors on the chopper drive board — HV341-01-10 troubleshooting for this fault often begins with oscilloscope verification of the phase current waveform under load.
Intermittent loss of holding torque at rest caused by a failing bootstrap capacitor in the high-side gate driver circuit, which presents as axis drift on vertical load-holding applications using Frame 34 motors.
Cable harness continuity failure at the drive-end connector due to repeated flex fatigue in the 10-foot integrated cable assembly, resulting in single-phase drop-out, audible motor growl, and excessive heat in the remaining active winding.
Frequently Asked Questions
Is the HV341-01-10 compatible with or a drop-in replacement for other Parker or third-party stepper drives?
The HV341-01-10 is mechanically and electrically similar to other Parker HV Series Frame 34 drivers, making it an HV341-01-10 replacement candidate for units like the Parker HV232-01-10 and HV233-01-10 in many installations, provided the supply voltage range and current rating are confirmed to match the motor nameplate. From a signal interface standpoint, the step/direction input on the HV341-01-10 is compatible with controllers that drive units like the Applied Motion Products ST5-S or Leadshine DM542, though connector pinouts will differ and wiring adaptation is required. Cross-brand substitution should always include verification of the motor's rated phase current against the 2.74 A RMS output of this driver before commissioning.
How do I know if my HV341-01-10 is worth repairing or should be replaced outright?
HV341-01-10 repair is generally cost-justified when the failure is confined to the driver PCB, gate drive circuitry, or the cable assembly — components that a qualified Parker VFD repair facility can source and replace at a fraction of new unit cost. Parker HV341-01-10 units that have sustained transformer burnout from sustained overcurrent, physical damage to the motor interface connector housing, or corrosion-related trace damage across multiple board layers are more difficult to restore economically and may warrant replacement instead. A key diagnostic indicator is whether the unit powers up and communicates enable state correctly — if the logic supply is functional but the output stage does not energize, the fault is almost always in the power section and is repairable. Units with visible carbon scoring on the output transistors or melted cable insulation near the drive-end connector should be evaluated in person by a technician before a repair-or-replace decision is made.
Where can I get HV341-01-10 repair service with a warranty?
Flexa Systems, based in Lewisville TX, provides HV341-01-10 repair service with a 2-year warranty on all repaired and refurbished units, with a standard turnaround of 5 to 7 business days from receipt of the unit. Customers across the country benefit from Flexa's nationwide service model — simply ship the failed drive, and a full diagnostic report is provided at no charge before any repair work is authorized. If your timeline cannot accommodate repair, Flexa also maintains exchange inventory, so customers looking to buy HV341-01-10 USA stock can source a tested, warrantied replacement unit immediately while their original is being serviced. Contact Flexa Systems directly to confirm current HV341-01-10 for sale availability and to initiate a free diagnostics evaluation for your failed unit.
Where can I get HV341-01-10 repair service with a warranty?
Flexa Systems provides professional HV341-01-10 repair service from our facility in Lewisville, TX, serving customers nationwide. Standard turnaround is 5–7 business days from receipt and all repaired units ship with a 2-year warranty. Rush service (2–3 business days) is also available.
Flexa Systems specializes in Parker HV341-01-10 variable frequency drive repair, supplying refurbished and new units backed by a 2-year warranty. All drives are load-tested before shipping. Serving industrial facilities nationwide from Lewisville, TX.
Technical Specifications
Part Number:
HV341-01-10
Manufacturer:
Parker
Current:
2.74 A RMS
Type:
Compumotor
Ask for Price
