B&R 5PC900.TS17-01
Repair option: component-level repair is available for this model — free diagnostics, a 2-year warranty, and a 5–30 business day turnaround. Repair typically costs 40–70% of a new unit, saving you 30–60%. Request a repair quote.
B&R 5PC900.TS17-01 repair service is available through Flexa Systems for facilities experiencing unexpected downtime on this compact industrial touch screen panel PC unit, and our team also stocks the 5PC900.TS17-01 refurbished for drop-in replacement when lead times on new units are unacceptable. The 5PC900.TS17-01 is a 17-inch touch screen front panel designed for use with B&R's Power Panel PC 900 series, delivering resistive touch input with a 1280x1024 SXGA resolution display built to withstand continuous operation in harsh manufacturing environments. Facilities searching for 5PC900.TS17-01 repair near me often find that local automation shops lack the B&R-specific firmware tools and calibration procedures this unit requires, making a specialized provider essential. The panel integrates into machine-level HMI and supervisory control architectures across food and beverage processing, automotive assembly, and pharmaceutical packaging lines where panel integrity directly impacts OEE. Because the 5PC900.TS17-01 is frequently paired with B&R's VFD and motion control ecosystem, industrial VFD repair and HMI panel repair are often addressed together when troubleshooting system-level faults. For engineers working through 5PC900.TS17-01 troubleshooting steps, common issues include touch screen delamination, backlight inverter failure, and controller board communication faults that require component-level diagnostics rather than simple swap-out. Flexa Systems provides free diagnostics on every inbound unit so customers understand the failure root cause before authorizing repair work. Our 5PC900.TS17-01 repair service is backed by a 2-year warranty, giving production teams confidence that repaired units will hold up under continuous duty cycles.
The 5PC900.TS17-01 is compatible with B&R's Power Panel PC 900 series mainframe assemblies and interfaces directly with B&R Automation Studio 4.x for project deployment, HMI configuration, and firmware updates over USB or Ethernet. B&R 5PC900.TS17-01 integration is supported across Automation PC 910 and Automation PC 920 base units, and the panel communicates via B&R's internal panel link bus, making it a verified 5PC900.TS17-01 replacement for the earlier 5PC900.TS15-01 15-inch variant in installations where mounting cutout dimensions allow the upgrade. The unit is also compatible with B&R X20 and X67 I/O systems when deployed in a broader control cabinet architecture, and it supports POWERLINK, Modbus TCP, and EtherNet/IP network topologies for supervisory data exchange. Specific compatible base unit models include the 5PC900.X945-11, 5PC900.X945-04, 5PC901.X945-11, and 5PC900.X855-11, all of which accept the TS17-01 front panel assembly through B&R's standardized mechanical and electrical interface.
- DC bus overvoltage fault on the connected B&R ACOPOSmulti drive triggered by backplane communication errors originating from the 5PC900.TS17-01 controller board losing its Automation Runtime task cycle sync during high display refresh loads.
- Touch screen digitizer layer separation causing persistent phantom input registration — a documented 5PC900.TS17-01 fault in units operating above 45°C ambient with inadequate cabinet ventilation, often misdiagnosed as a software calibration issue.
- Backlight inverter failure resulting in a fully black display while the unit continues to run Automation Runtime normally, which complicates 5PC900.TS17-01 troubleshooting because the system appears unresponsive but is actively executing PLC tasks.
- CompactFlash card controller degradation on the onboard storage interface causing repeated Automation Runtime boot failures with BIOS POST errors — accelerated by high-vibration installations on press or stamping machinery where the card socket develops intermittent contact resistance over time.
Technical Specifications
| Manufacturer: | B&R |
| Type: | Circuit Board |
