Siemens
6AV2 124-0MC01-0AX0
No reviews
SKU: 2100000021826
$1,175.00
Contact us for pricing
2-Year Warranty
Free Diagnostics
5–30 Day Turnaround
Nationwide Service
6AV2 124-0MC01-0AX0 repair service is available for the Siemens SIMATIC HMI TP1200 Comfort Panel, a 12.1-inch widescreen touchscreen operator interface built for demanding process visualization and machine control environments — and Siemens 6AV2 124-0MC01-0AX0 repair or 6AV2 124-0MC01-0AX0 refurbished units are among the most requested from facilities running continuous production lines. The TP1200 Comfort Panel features a 1280 x 800 pixel TFT display with 16 million colors, capacitive multi-touch input, and 24 VDC power supply compatibility, making it a workhorse in automotive assembly, water treatment, food processing, and packaging operations. For facilities searching for 6AV2 124-0MC01-0AX0 troubleshooting support after a display failure or communication dropout, understanding the unit's dual Ethernet ports, PROFINET IO connectivity, and USB host/device interfaces is essential to accurate diagnosis. The panel integrates with TIA Portal for project engineering and supports PROFIBUS, MPI, and Industrial Ethernet protocols natively, which means industrial VFD repair and HMI repair technicians must be familiar with the full Siemens communication stack when servicing it. Operators experiencing 6AV2 124-0MC01-0AX0 fault codes related to communication timeouts or touch calibration drift often find the root cause in corrupted project memory or failed internal capacitors rather than the display assembly itself. If you're wondering where to repair Siemens VFD and HMI equipment with fast turnaround, Flexa Systems offers free diagnostics on every unit received. Our facility in Lewisville TX services customers nationwide, returning panels to full factory specification before shipment.
Technical Specifications
Part Number
6AV2 124-0MC01-0AX0
Manufacturer
Siemens
Package / Type
BOX/MODULE
Compatibility
The Siemens 6AV2 124-0MC01-0AX0 is compatible with the full SIMATIC S7 controller family, including the S7-1200, S7-1500, S7-300, and S7-400 PLCs, communicating via PROFINET IO or MPI/PROFIBUS DP depending on the network topology in use. Siemens 6AV2 124-0MC01-0AX0 integration with TIA Portal V13 SP1 and higher is required for project configuration, and the panel supports WinCC Comfort runtime for advanced scripting and alarming. The 6AV2 124-0MC01-0AX0 replacement for earlier panels such as the 6AV6 648-0CC11-3AX0 (TP1200 Basic) or the 6AV2 123-2MB03-0AX0 (TP1200 Comfort previous generation) is straightforward when re-engineering the HMI project in TIA Portal, though screen resolution and tag count differences must be accounted for. The panel's dual PROFINET ports also support daisy-chain network topologies alongside Siemens SCALANCE network switches and S120 drive systems that use the SINAMICS Startdrive engineering tool.
Service Options
Repair Service
Ship your faulty 6AV2 124-0MC01-0AX0 to our facility. Our certified technicians perform IGBT testing, capacitor inspection, gate driver diagnostics, and full load testing. Typical turnaround: 5–7 business days. 2-year warranty included.
Refurbished
In-stock Siemens 6AV2 124-0MC01-0AX0 variable frequency drive, reconditioned to OEM specifications and verified under load. Ships immediately. 2-year warranty included.
Brand New
New 6AV2 124-0MC01-0AX0 in original Siemens packaging. Full manufacturer warranty applies. Contact us to confirm availability and lead time.
Common Failure Modes
Touchscreen input failure where the capacitive overlay stops registering touch events in one quadrant — common during 6AV2 124-0MC01-0AX0 troubleshooting when the unit has been exposed to coolant mist or sustained vibration loosening the flex cable connector at the touch controller board.
Blank display with backlight active on power-up, caused by a failed LVDS signal cable or degraded LCD driver IC — the panel boots normally as confirmed by network communication remaining active, but no image is rendered on screen.
PROFINET communication loss fault where the panel repeatedly drops its IO controller connection and triggers a 'Connection to PLC interrupted' alarm, typically traced to a failed internal Ethernet PHY chip or corrupted MAC address in flash memory on the 6AV2 124-0MC01-0AX0 unit.
Internal 24 VDC power rail collapse due to a failed bulk capacitor on the main board, causing random reboots or failure to complete the boot sequence — a fault pattern frequently misdiagnosed as a project file corruption issue during initial 6AV2 124-0MC01-0AX0 fault investigation.
Frequently Asked Questions
Is the 6AV2 124-0MC01-0AX0 compatible with other HMI panels or interchangeable with older Siemens models?
The 6AV2 124-0MC01-0AX0 is compatible with projects originally developed for the 6AV2 123-2MB03-0AX0 TP1200 Comfort predecessor, provided the TIA Portal project is migrated and tested for any resolution or tag mapping differences. It can also serve as a functional 6AV2 124-0MC01-0AX0 replacement for the 6AV6 644-0AB01-2AX0 MP277 10-inch panel in applications where the engineering team is willing to redesign screen layouts to accommodate the larger 12.1-inch format and updated WinCC Comfort runtime. Both PROFIBUS and PROFINET communication parameters carry over cleanly in most S7-300 and S7-1500 installations, making the transition manageable for experienced system integrators.
How do I know if my 6AV2 124-0MC01-0AX0 is worth repairing or if I should replace it outright?
In most cases, 6AV2 124-0MC01-0AX0 repair is the more economical path unless the panel has suffered physical frame damage, a fully cracked display glass, or liquid ingress that has corroded multiple board layers simultaneously. The Siemens 6AV2 124-0MC01-0AX0 is engineered with modular internal assemblies — the display module, main CPU board, and power supply board are each serviceable independently, which means a backlight failure or communication chip fault does not require replacing the entire unit. Fault conditions like PROFINET dropout, single-zone touch failure, or boot loop caused by capacitor degradation are all repairable at the component level by a qualified technician with access to Siemens board-level documentation. If free diagnostics confirm the CPU board is intact and flash memory is uncorrupted, repair turnaround is typically five to seven business days.
Where can I get 6AV2 124-0MC01-0AX0 repair service with a warranty?
Flexa Systems, based in Lewisville TX, provides depot repair and testing for the 6AV2 124-0MC01-0AX0 with a 2-year warranty covering all repaired components and labor, and ships to customers nationwide with typical five to seven business day turnaround from receipt. Every unit goes through a full functional test bench cycle that validates touchscreen calibration, all communication ports, display uniformity, and power supply rail tolerances before it ships back. If you need to buy 6AV2 124-0MC01-0AX0 USA stock immediately while your failed unit is in repair, Flexa also carries refurbished exchange units that are tested to the same standard and covered under the same warranty terms. Contact Flexa Systems directly to submit your unit for free diagnostics — no repair fees are charged if the unit is evaluated and deemed non-repairable.
Where can I get 6AV2 124-0MC01-0AX0 repair service with a warranty?
Flexa Systems provides professional 6AV2 124-0MC01-0AX0 repair service from our facility in Lewisville, TX, serving customers nationwide. Standard turnaround is 5–7 business days from receipt and all repaired units ship with a 2-year warranty. Rush service (2–3 business days) is also available.
Flexa Systems specializes in Siemens 6AV2 124-0MC01-0AX0 variable frequency drive repair, supplying refurbished and new units backed by a 2-year warranty. All drives are load-tested before shipping. Serving industrial facilities nationwide from Lewisville, TX.
Repair option: send in your faulty unit for component-level repair — $1,175.00 with free diagnostics, a 2-year warranty, and a 5–30 business day turnaround. Repair typically costs 40–70% of a new unit, saving you 30–60%. Learn more about our HMI repair service.
Technical Specifications
Part Number:
6AV2 124-0MC01-0AX0
Manufacturer:
Siemens
Type:
BOX/MODULE
Ask for Price
