Allen-Bradley
2711-K6C9
No reviews
SKU: 2100000021567
$2,900.00
Contact us for pricing
2-Year Warranty
Free Diagnostics
Ships in 1–2 Business Days
Nationwide Service
Allen-Bradley 2711-K6C9 repair service is the specialty of Flexa Systems, where our technicians restore this PanelView 600 color keypad terminal to full factory specification — and if your timeline is critical, we also stock Allen-Bradley 2711-K6C9 refurbished units ready to ship. The 2711-K6C9 is a 6-inch color touchscreen/keypad operator interface terminal from Rockwell Automation's PanelView 600 series, powered by 120/240V AC and equipped with both RS-232 and DH-485 communication ports for direct connection to Allen-Bradley PLC networks. Facilities running 2711-K6C9 troubleshooting in-house often discover that display degradation, keypad membrane failures, and communication port faults are the primary culprits taking these panels offline. This terminal is commonly deployed in food and beverage processing, water treatment, discrete manufacturing, and packaging lines where operators need a reliable human-machine interface with tactile keypad feedback alongside color display output. Because the unit bridges RS-232 and DH-485 protocols natively, it connects directly to SLC 500 and MicroLogix controllers without additional communication modules, making industrial VFD repair and broader control system servicing far more straightforward. Customers searching for 2711-K6C9 repair near me can ship their unit directly to our Lewisville, TX facility and receive free diagnostics before any repair commitment. Our team handles everything from backlight replacement and touchscreen digitizer restoration to full communication port rebuilds, returning panels that perform exactly as they did on the original production floor.
Technical Specifications
Part Number
2711-K6C9
Manufacturer
Allen-Bradley
Package / Type
PanelView 600
Compatibility
The 2711-K6C9 is compatible with Allen-Bradley SLC 500 processors (including the 1747-L532 and 1747-L543) and the full MicroLogix family via DH-485 network using the AIC+ Advanced Interface Converter (1761-NET-AIC), making Allen-Bradley 2711-K6C9 integration into existing ladder-logic-controlled lines straightforward. The RS-232 DF1 port allows point-to-point communication with ControlLogix and CompactLogix processors when paired with the appropriate serial cable and RSLinx Classic gateway configuration. For applications where the 2711-K6C9 replacement is needed in a panel already wired for DH-485, units such as the 2711-K6C3 (monochrome keypad) and 2711-E6C1 (PanelView Enhanced) share overlapping physical footprints and communication pinouts, simplifying migration. The terminal is also compatible with Panel Builder 32 and RSView Machine Edition software for application file development, and it can coexist on a DH-485 network alongside other nodes such as the 1747-KE and 1761-NET-AIC interface modules.
Service Options
Repair Service
Ship your faulty 2711-K6C9 to our facility. Our certified technicians perform IGBT testing, capacitor inspection, gate driver diagnostics, and full load testing. Typical turnaround: 5–7 business days. 2-year warranty included.
Refurbished
In-stock Allen-Bradley 2711-K6C9 variable frequency drive, reconditioned to OEM specifications and verified under load. Ships immediately. 2-year warranty included.
Brand New
New 2711-K6C9 in original Allen-Bradley packaging. Full manufacturer warranty applies. Contact us to confirm availability and lead time.
Common Failure Modes
Backlight inverter failure causing the 6-inch color display to go dark while the unit remains powered and communicating — one of the most frequent 2711-K6C9 fault conditions, typically presenting after 5–8 years of continuous operation in high-ambient-temperature enclosures.
DH-485 communication loss fault where the panel repeatedly displays 'No Communication' and resets the network token, traced to degraded RS-485 transceiver ICs on the communication daughterboard — a known 2711-K6C9 troubleshooting issue on units exposed to electrical noise from adjacent VFD output wiring.
Keypad membrane delamination causing intermittent or non-responsive function keys, particularly F1 through F4, resulting from repeated thermal cycling in enclosures without climate control — the tactile dome array loses contact continuity and generates erratic input signals to the processor board.
Internal SRAM battery depletion causing application loss on power cycle — the 2711-K6C9 stores its PanelView application in battery-backed SRAM, and when the onboard lithium cell drops below threshold, the terminal boots to a blank project and requires full application reload from the programming terminal.
Frequently Asked Questions
Is the 2711-K6C9 compatible with or interchangeable with other PanelView 600 models or newer Allen-Bradley terminals?
The 2711-K6C9 compatible with other PanelView 600 series terminals in the same keypad/color subfamily, most notably the 2711-K6C8 (DC-powered variant) and the 2711-K6C1 (RS-232 only), which share the same application file format and physical cutout dimensions. If you are migrating to a newer platform, the PanelView Component C600 (2711C-T6T) is the closest modern equivalent, though it requires application conversion using PanelView Component Designer rather than Panel Builder 32. Cross-brand substitution with terminals such as the Maple Systems HMI5070 is possible electrically, but DH-485 protocol support must be verified against the specific firmware revision before deployment.
How do I know whether my 2711-K6C9 is worth repairing or should be replaced outright?
A 2711-K6C9 repair is generally cost-effective when the failure is isolated to wear components — backlight inverters, keypad membranes, SRAM batteries, or communication port ICs — all of which Flexa Systems stocks and replaces routinely. The Allen-Bradley 2711-K6C9 crosses into replace territory when the main processor board shows signs of thermal cracking, burnt traces from a surge event, or corrosion damage from coolant or chemical exposure that has compromised multiple board layers simultaneously. If the unit powers on, communicates intermittently, or displays a partial screen, it is almost always recoverable; units that show zero response to power-up with no visible physical damage are also strong repair candidates because the fault is typically a failed power supply section rather than the display assembly. Send the unit in for free diagnostics and our technicians will confirm repairability before any work begins.
Where can I get 2711-K6C9 repair service with a warranty?
Flexa Systems, based in Lewisville, TX, provides 2711-K6C9 repair service with a 2-year warranty on all completed repairs, covering both parts and labor for any recurrence of the original fault condition. Our standard turnaround is 5–7 business days from receipt, and we offer expedited options for facilities with urgent downtime situations. We provide nationwide service with prepaid shipping labels for inbound units, and customers looking to buy 2711-K6C9 USA stock can also purchase certified 2711-K6C9 refurbished units directly from our inventory, each tested to full factory communication and display specification before shipment. Contact our team directly to receive a repair quote or to confirm in-stock availability on exchange units.
Where can I get 2711-K6C9 repair service with a warranty?
Flexa Systems provides professional 2711-K6C9 repair service from our facility in Lewisville, TX, serving customers nationwide. Standard turnaround is 5–7 business days from receipt and all repaired units ship with a 2-year warranty. Rush service (2–3 business days) is also available.
Flexa Systems specializes in Allen-Bradley 2711-K6C9 variable frequency drive repair, supplying refurbished and new units backed by a 2-year warranty. All drives are load-tested before shipping. Serving industrial facilities nationwide from Lewisville, TX.
Repair option: send in your faulty unit for component-level repair — $1,800.00 with free diagnostics, a 2-year warranty, and a 5–30 business day turnaround. Repair typically costs 40–70% of a new unit, saving you 30–60%. Learn more about our HMI repair service.
Technical Specifications
Part Number:
2711-K6C9
Manufacturer:
Allen-Bradley
Type:
PanelView 600
